0.6mm PTFE Mesh Conveyor Belt Customizable Chemical Resistance
  • 0.6mm PTFE Mesh Conveyor Belt Customizable Chemical Resistance
  • 0.6mm PTFE Mesh Conveyor Belt Customizable Chemical Resistance
  • 0.6mm PTFE Mesh Conveyor Belt Customizable Chemical Resistance
  • 0.6mm PTFE Mesh Conveyor Belt Customizable Chemical Resistance
0.6mm PTFE Mesh Conveyor Belt Customizable Chemical Resistance

0.6mm PTFE Mesh Conveyor Belt Customizable Chemical Resistance

Place of Origin Guangdong, China
Brand Name KangHongJin
Certification RoHS
Model Number R10 Series
Product Details
Product Name:
PTFE Belt
Material:
PTFE +PET
High Light:
PTFE, Non-stick PTFE Conveyor Belt, PTFE Seamless Heat Sealing Belt, PTFE Endless Fusing Belt
Product Description

R10 Series Black Anti-Aging PTFE Belt Belt Vacuum Sealing Endless PTFE Seamless Conveyor Belt

DESCRIPTION

R10 series Black belt coated with PTFE resin by using a unique process technology. It overcomes

the phenomenon that the connection of the conveyor belt interface is easy to break in the past, and
solves the problem of poor running stability and deviation because of unequal circumference of the
joint.

 Part
 Material
 Thickness
 Width
 Color
 R08
 PTFE film
 0.01-0.2mm
 ≤1300mm
 White, black,
 red, yellow,   green, blue, etc
 R09
 Fep film
 0.025-0.25mm
 ≤1250mm(tape casting);   ≤550mm(blow m olding)
 Transparent
 R10
 PTFE belt
 0.13-1mm
 ≤2400mm
 Brown, white,   black, etc
 R11
 PTFE mesh belt
 0.6mm
 Custom
 Brown, black

 R12
 PTFE cloth
 0.08-1mm
 ≤2400mm
 Brown, white,   black, etc

 R13
 PTFE tape
 0.08,0.13,0.18,
 0.25mm(film base);
 0.13,0.16,0.18,
 0.25,0.3,0.4mm
 (cloth base)
 ≤500mm(film base) ;
 ≤1250mm(cloth base)
 Gray(film base);
 brown, white,
 black, etc
 (cloth base)

ADVANTAGES

1. Insulation: not affected by the environment and frequency; volume resistance up to 1018 Ω · cm; small dielectric loss; high breakdown voltage

2. High and low temperature resistance: can be used at -60~360℃

3. With the smallest friction coefficient of plastics, it is an ideal oil-free lubricating material

3. Non-stick PTFE film provides an exceptionally slick surface for easy clean-up

4. Atmospheric aging resistance, radiation resistance and low permeability: long-term exposure to the atmosphere, the surface and performance stay the same
5. Chemical resistance and weather resistance: polytetrafluoroethylene is almost impervious to any chemical attack except for molten alkali metals.



INSTRUCTIONS

1. Drying machine for non-woven textile, textile printing, silk-printing and dyeing machine;

2. Shrinking machine for garment fabric, high-frequency and UV dryer;

3. Conveyor belt for hot-air dryer, various of food baking, quick-frozen machines;
4. Oiling machine for paper glazing and waxing, plant engineering;
5. Separating sheet for hardboard production etc.
6. Other applications which requires chemical and high - temperature resistance.
